<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by B18Sleeper &raquo;</TD></TR><TR><TD CLASS="quote">got a angled side shot of that? to show both fenders and how it stands from the front? </TD></TR></TABLE>

No haven't got a chance yet, weather has been crazy here in houston, its has been raining and cold.

<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by dartdc97 &raquo;</TD></TR><TR><TD CLASS="quote">hey 96cxt, what size turbo is that? and what throttle body is bolted up?</TD></TR></TABLE>

It's a T74, Throttle body is an Edlebrook 75mm and you'll need the adpt. plate to make it fit on the intake manifold. But this is a race TB cause there is no idle control.



thats cool man when the weather gets better if u get a shot post it up i would love to see how that sits



here's two of my new setup. i still need to do some tucking and rewiring, but i have to wait until it gets warmer out.



[QUOTE=96cxt]Here's my set-up.



Looking good You still on stock mounts? No problems with that monster trying to jump out? LOL





Test fitting my manifold/turbo/downpipe before I pull the engine for a Build..





<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by ...JDM EG6... &raquo;</TD></TR><TR><TD CLASS="quote">
Looking good You still on stock mounts? No problems with that monster trying to jump out? LOL</TD></TR></TABLE>

Thanks man. Yes still on stock mounts with inserts, no problem yet. BUt I'm thinking about changing them soon. Just saving up for a twin disc clutch first.



guys love the pics keep them coming...i cant wait till i get started on my motor i just hope mine turns out half as good as these





fun setup while it lasted, let a friend put the oil return on after i cut the crossmeber a little bit, 2 days later it came off and i got a rod knock , i got it alot cleaner too, painted charge pipes, and remounted overflow, got my slim fan the day after it blew


Modified by g2lsvtec at 1:40 AM 2/25/2007



Anymore 40r or 42r Pics???

...thinkin bout going bigger



nice pics...keep em coming





<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by civic_ex_95 &raquo;</TD></TR><TR><TD CLASS="quote">

</TD></TR></TABLE>

Love that manifold.... Makes me wanna boost my Y8



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by ltrkstr2k &raquo;</TD></TR><TR><TD CLASS="quote">

Love that manifold.... Makes me wanna boost my Y8</TD></TR></TABLE>

ya it was a one off design that seems to work pretty well for a d16.. should be getting it dyno tuned here in the next couple of weeks so we can see how good it really works.





WOW I love this thread!!! Here are a couple pics of mine... sorry about the crappy sidekick pics



Its a work in progress...new pics in a week or so if the weather cooperates!



we're both running a cc-fab manifold

hmt4life schister





nothing special



Where is everyone relocating there map sensor?



Are you talking about running an aftermarket one? I left mine where it was.



Dang, thought this was a prelude only thread.


Modified by genocide43110 at 6:13 PM 3/6/2007



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by hatchbkdrvr &raquo;</TD></TR><TR><TD CLASS="quote">Where is everyone relocating there map sensor?</TD></TR></TABLE>

My 3 BAR is on the passenger side firewall...
