DOes anybody have a good website that shows you how to remove a head correctly??? or a good wirte up?? i tried searching but came up with "NOTHING"



ummm... just remove it.

buy a haynes manual



the intake manifold does NOT need to be removed. It is much MUCH easier to pull it with it attached to the head, THEN disassemble it.


1. Remove valve cover
2. Remove timing belt(or take it off the pulleys and lay it to the side).
3. Remove all Hoses & wiring that connect to the throttle body, and various other places.
4. If you have a B18C motor, you need to pull your cams to get to the bolts Otherwise remove all the bolts.
5. Follow The correct loosening & tightening sequence



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by vtecluder97 &raquo;</TD></TR><TR><TD CLASS="quote">the intake manifold does NOT need to be removed. It is much MUCH easier to pull it with it attached to the head, THEN disassemble it.


1. Remove valve cover
2. Remove timing belt(or take it off the pulleys and lay it to the side).
3. Remove all Hoses & wiring that connect to the throttle body, and various other places.
4. If you have a B18C motor, you need to pull your cams to get to the bolts Otherwise remove all the bolts.
5. Follow The correct loosening & tightening sequence</TD></TR></TABLE>

even the ls needs the cams removed to get to the head bolts, i konw a d-series motor you can take the head off withou removing the cam



Go here and download the Helms manual on .pdf form. Then read up on the procedures to remove the head. Good luck!

http://www.hondahookup.com/manuals/



Thats a good link.

I like alldata though



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by 97tegGS &raquo;</TD></TR><TR><TD CLASS="quote">Thats a good link.

I like alldata though </TD></TR></TABLE>

alldata?



c-speedracing.com......... has good info..they should have it there



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by Rod. &raquo;</TD></TR><TR><TD CLASS="quote">c-speedracing.com......... has good info..they should have it there</TD></TR></TABLE>


or that, try team integra too, iuno how good they are but i thought i saw a write up on how to do it.....
PS: Rod your avatar is hilarious



dont worry so much about taking it off. Make sure that you label everythig, IE plugs, wires, ETC. Then take your time putting it all back together.

It took me about 2 hours to take the head off. And about 12 to put it back on.



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by hamB18C5 &raquo;</TD></TR><TR><TD CLASS="quote">dont worry so much about taking it off. Make sure that you label everythig, IE plugs, wires, ETC. Then take your time putting it all back together.

It took me about 2 hours to take the head off. And about 12 to put it back on. </TD></TR></TABLE>

damn, lol.....you take about a billion breaks and get lost?



well, I was being very particular with everthing. Just because I didn't want to **** up my type-R. Yeah there were quite a few cig breaks. It took us a while to get the crank pulley off. I actually had to take it to a diesel place to use there impact gun! PITA!

But really I wanted the TDC and all that to be just perfect. I figure its worth the extra time to get it done, rather than create more issues.



Here was the problem


shortcut to remove head


all put back together
