OBD2b 3 wire Alternator to OBD1 4 wire help - searched
09-29-2006, 03:34 PM
#1
Honda-Tech Member
Thread Starter
OBD2b 3 wire Alternator to OBD1 4 wire help - searched
Im doing a B16 swap in my 99 hatch. OEM alternator is 3 wire: white/blue, black/ yellow, and white red. I've beed searching and all I can find is 4 wire to 4 wire conversion. Im wanting to use the newer 4 wire alt. Is there any way to wire it to work?
Thanks
Thanks
09-29-2006, 08:20 PM
#2
Honda-Tech Member
Thread Starter
Re: OBD2b 3 wire Alternator to OBD1 4 wire help - searched (Slothy)
I've tried to use my 3 wire D-series, but the belt adjusting bracket doesn't line up
(circled)
Can I go:
Blk/Yel -- blk/yel
Wht/ blu -- wht/blu
blue -- red
and disregard the whte/ yellow -- wht/ green (I do not have the white/green)
Thanks again.
(circled)
Can I go:
Blk/Yel -- blk/yel
Wht/ blu -- wht/blu
blue -- red
and disregard the whte/ yellow -- wht/ green (I do not have the white/green)
Thanks again.
09-30-2006, 04:12 PM
#5
Honda-Tech Member
Thread Starter
Re: OBD2b 3 wire Alternator to OBD1 4 wire help - searched (Slothy)
Just disregard the final wire (wht/yel), car will charge fine without it. No CEL.
Just use the 3 wires mentioned above, no problems
Just use the 3 wires mentioned above, no problems
