How to clean corroded harness connections
#1
Honda-Tech Member
Thread Starter
How to clean corroded harness connections
An intermittent speedo in my EM1 led me to a corroded connector plug on my wiring harness at the Variable Speed Sensor and also on the pins of the VSS itself.
Here's how I chose to clean them.
Here's the problem:
Items needed: Compressed air not pictured.
Diamond-tipped terminal cleaning tool kit cost me $28 shipped on Amazon.
Salt 0.45
Vinegar 1.00
Distilled water 1.00
Dielectric grease 1.50
Warm in the microwave for a minute, about 200 mL (half bottle) of white vinegar and add about a tablespoon of salt.
Stir until salt is dissolved, adding a bit more vinegar to cool the solution slightly and help the salt dissolve.
Fill a syringe or turkey baster with the solution.
Flush out the terminal contacts until the corrosion is all gone.
IMPORTANT Flush with warm distilled water once you feel the terminals are clean enough. This solution will make corrosion like crazy if you don't rinse it out.
Grab your girlfriend's toothbrush.
Clean that MFer, because racecar.
Optional, use diamond tipped terminal cleaning tool to ensure good conductivity.
Repeat the steps for the female side of the connection.
Again, I'm going to say this. IMPORTANT Flush with warm distilled water once you feel the terminals are clean enough. This solution will make corrosion like crazy if you don't rinse it out.
The tool can spread open so that you can lightly file the female terminal's insides.
Blow out both connections with air, if possible.
Add dielectric grease to the contacts and plug in the connector.
Before:
After:
Enjoy!
