B20z1 block
b18c6 crank girdle and sump
golden eagle block guard.
b16a1 cams/head
**** ebay 1.85 inch header
test pipe
skunk 2 pro intake manifold
spoon 70-68mm ITR throttle body
2.75inch short ram
345cc lude injectors
afr's mapped on BRE (obd0)

185flywheel, 148tq (lots more to come with tyi-y and ITR cams)

at least 6000 miles on it and counting!
rev limit at 8200 rpms (never heads that far as peak is at 7300 rpm lol)



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by 7601chexplicit &raquo;</TD></TR><TR><TD CLASS="quote">2000 civic si
rs machine 84mm pistons
eagle rods
Ls micropolished crank
stock 00 b16 head
stock cams
arp head studs
aebs intake manifold
68mm tb
dc headers
aem intake
9lbs exedy flywheel
chipped p06 running vtec
stock injectors and fuel pump

shifting at 8200.... 2000 miles so far, waiting on my cams to get here to get dyno tuned.
had to settle for obx stage 1, wanted Blox B's, but they were sold out and im very impatient. hoping for at least 200whp.
what do you guys think?</TD></TR></TABLE>

i think by using those cams you better buy a magnetic oil plug for your oil pan. sorry to say buddy but those cams have been proven to eat your rockers and cause alot of damadge. should have saved for blox. dont use them unless you like flushing money down the toilet. PLEASE PLEASE PLEASE search these cams before you install them. dont just say [freak] it and install anyway thinking you dont want to lose out. send them back unopened and try to get a refund. SORRY THIS IS OFF TOPIC BUT I WOULD HATE TO SEE THIS GUYS BUILD GO TO ****.



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by eg714 &raquo;</TD></TR><TR><TD CLASS="quote">good thread how many of you true street car guys do long distance trip (say 500 miles each way) driving with your stock sleeve b20vtec build? reason i ask is im going to be done with my 1st time b20vtec build soon and i travel alot from so cal to nor cal like once every other month </TD></TR></TABLE>

As long as the setup is tuned and your not holding @ 8000 rpms for the hole 500 mile trip, I wouldnt worry. I have 6600 DD miles since Aug 07 and don't think twice about taking long trips. Next month I'll be going 3.5 hrs to VIR, tracking for 2 days then driving back. No worries



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by ivan93egreppin210 &raquo;</TD></TR><TR><TD CLASS="quote">

i think by using those cams you better buy a magnetic oil plug for your oil pan. sorry to say buddy but those cams have been proven to eat your rockers and cause alot of damadge. should have saved for blox. dont use them unless you like flushing money down the toilet. PLEASE PLEASE PLEASE search these cams before you install them. dont just say [freak] it and install anyway thinking you dont want to lose out. send them back unopened and try to get a refund. SORRY THIS IS OFF TOPIC BUT I WOULD HATE TO SEE THIS GUYS BUILD GO TO ****. </TD></TR></TABLE>

lol, f@ck! good looking out. i spent the whole day researching those OBX cams and sure enough theyve been proven to eat up rockers.
im in the process of how im going to go about with the return. thats what i get for waiting till the last minute. i was trying to have my blox b's here and installed by next friday to get to Church's and get dyno tuned, but when i was finally going to order them they were sold out. . Damn, and i have a big race that night.



Well I determined that the weakest link with my B20vtec build is not the sleeves, its the b16 differential. After eliminating two V8's at the track, the 3rd attempt at one ended with my diff exploding. Good times



DON'T BE PUSSIES! STOCK-BLOCK ROCKS!

I built this thing way back in 2002...

214 whp 156 tq B20VTEC

40,000 miles and counting
Numerous 9000rpm stabs
Never Overhauled!
Trips to Strip
Numerous Street-races years ago
VTEC engaged as many times as possible during trips to and from work
Never had a problem
No Girdles or Blockguards

Engine:
Skunk2 v1 Intake Manifold
B16a2 Head (mild port/polish, dimpled and milled .015")
Stock B16a2 Valvetrain!
ARP Headbolts
B16a2 Oil Pump/Water Pump
RC 310cc Injectors
Endyn PCV Breather Kit
GSR Vtec Timing Belt
Spoon 70mm Throttle Body
JDMHondaparts Cam Gears
Skunk2 Stage1 Cams
JHPUSA LSVTEC Oil Line
JE Pistons (10.5:1)
Eagle B18b/B20b Rods w/ ARP Rod Bolts
Honda Factory Bearings (Main/Rod)
Honda Front/Rear Main Seals
Honda B20b/z Head Gasket
B20B JDM block
No Girdle
AEM 99-00 Civic Si intake
Bosch Platnum Plugs #4227 $1.79each
Transmission:
B16a2 Tranny
Spoon lightweight flywheel (prebalanced 8.8 lbs factory is 16.9lbs)
ACT/Hyperclutch Street Stage 1
Phantom Grip LSD
Electronics:
Skunk2 Chipped P28 9500rpm fuel cut
VAFC1
Exhaust:
DC JDM 4-1 Ceramic Header (ported)
Thermal Research and Development 3.0" Exhaust - No cat



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by Slothy &raquo;</TD></TR><TR><TD CLASS="quote">Well I determined that the weakest link with my B20vtec build is not the sleeves, its the b16 differential. After eliminating two V8's at the track, the 3rd attempt at one ended with my diff exploding. Good times </TD></TR></TABLE>


Sorry to hear about your tranny, hope you get it back together soon
keep us updated.
I have my old ls diff, if your interested IM me.



40,000 miles that's some serious Honda reliability!
Solid build, keep us updated



***1st page updated***

Just got back from ITR Expo 8, it was hot as He!! but definitly worth the trip.
Put another ~100 miles on track + another 900 DD with no issues to speak of.

TURN 5a VIR FULL COURSE



I am currently in the process of building another b20. I had one two years ago that never had any problems mechanically what so ever. I built the motor myself and it made 230hp and 175 tq. The car was my daily driver and it saw 75 miles a day and numerous beatings at the track and street races. It never overheated or had any sleeve issues. the setup was
-b20z stock bore w/hone
-84 mm RS ITR pistons when they first came out
-stock rods w/ arp bolts
-stock crank
-ported gsr head
-ported blox manifold, 70 mm tb
-s2s2 cams
-profab header w/ full 2.5 straight piping

on 22" slicks it ran 8.0 at 88mph in the 1/8th with a crappy 1.8 60 ft. no traction bars and full weight interior with power doors .

I put about 8k miles on it before it was stolen . Ill try to post pics later if you guys want to see the car and the motor.



im building a b20VTEC


Will let you guys know how it turns out in a couple of months.

is 12:1CR street able?



Trowing mine in this weekend!!! b20b 84 mm rs itr dome arp rod bolts
gsr head port n polished. with blox bs. skunk manifold rpm proffesional products 70 mm tb. anr header. 2 1/2 ex
440 rc. injectors
Will keep you updated plan 2 daily drive.



**** Updated 1st page stats *****
Car mods : SK2 camber kit & 3" custom exhaust

NASA SE Event @ CMP

Starting Mileage 230452
Now 7-16-08 240545
Total 1093


Daily Driven 9193 miles
Road Course 900 miles

A few laps






Modified by pasaunde at 10:53 PM 7/17/2008



Built in 2002

The build-

1992 stock B16 head/valvetrain
ITR cams
ITR intake manifold
ITR throttle body
OBD1 prelude injectors
stock headgasket
2000 stock JDM B20B shortblock
Stock pistons/rods/rod bolts
Piston valve reliefs were slightly enlarged
ARP head studs
AEM 99-00 Civic SI CAI
Comptech 4-2-1 standard street header
Hondata, tuned

Still runs fine, I would say setup has maybe 15-25k miles on it. Haven't really spent the time to figure it out. Compression test/leakdown is perfect. Just did a leakdown last month and numbers were pretty much 0 across the board.

All of it was OEM honda, never rebuilt or anything. 1992 b16 head just off a JDM longblock from japan and same thing with the block.

Motor makes decent power, between 165-190 depending on the dyno.



The build -

B20b
RS machine 84.5mm pistons
Endyn Block Posts
Stock rods with arp rod bolts
micro-polished b20 crank
gsr crank girdle /pickup / pan
Blox Intake manifold
Maxbore 62mm throttle body
345cc prelude injectors (thanks Rosko)
hytech replica big tube header
Blox Competition Pro 1's
skunk2 valvetrain
b16 head
Endyne breather kit
93 octane
Hondata s300

working on getting everything put together now, will keep ya up to date!



Went to another NASA HPDE, at the legendary "ROCK" in Rockingham NC. This old NASCAR track was recently bought and reopened for smaller venues. It's only about an hour from the house so thought I'd hang with some of my buds.

the 30 degree banks are no joke and the transitions form the infield to the banking are aggressive.

Latest count

~ 10,000 DD miles
1,000 Track miles

I plan to attend another weekend at CMP and Road Atlanta before the year is over. This should put me at around 1300 rack miles and 14000 total. Even though the engine is still running good I'll probably drop the oil pan and take a peak at the bearings sooner rather than later. The motor takes alot of abuse on-track and I'd hate to loose a hole motor for the cost of a few bearings.



Me and the boys










Modified by pasaunde at 10:33 PM 10/2/2008



b20b vtec
untouched block
b16a3 head
GSR cams
JG edlebrock manifold
68mm TB
JDM oem itr header
chipped PO6 ecu
ACT 6 puck clutch
stock flywheel and Pressure plate
98 GSR trans

10 gallon tank on a 94 CX hatch gives me 320 Highway miles

so i guess 32 high way miles per gallons which i think is awesome!!!!



b20 vtec made 226whp and 154 ft. lbs.
b20 block
84.5mm cp pistons 12.5 cr
eagle rods/ arp rod bolts
micropolished crank/ new bearings and arp bolts
type r oil and water pump
arp head studs
block guard
al new gaskets and such

b16 head full port and polish
full rev racing valve train
buddy club spec 4 cams
skunk 2 proseries cam gears
greddy timing belt
rc 440 injectors
aem fuel rail and pressure regulator
jdm itr mani and stock b16 tb
custom 3 inch intake
jdm itr header on 2.5 exhaust
walbro 255 lph fuel pump

tranny is b16 new synchros and bearings w/
jdm type r 4.7 final drive
jdm type r helical lsd
clutch master stage 5 clutch and exedy 9 lb. flywheel

motor tuned on s300 w/ chipped p28 on 93
motor has over 10,000 with no issues motor wise at all... still strong last compression test tapped out the gauge at over 280 all cylinders on 3 clicks...

sad track times though with a 13.1 at 107 with a 2.3 60 footer on bf 205's in a full interiored 2000 si coupe. slicks r needed badly



Nice build! Guys throw up any dyno plots or car pic if you have them. I'll probably start sending out IMs every few months so we can keep the information current.

Next stop (CMP) Carolina Motorsport Park

If anyone is going to be in the Carolina's and wants to come out and enjoy some awesome on track fun. Start getting your track tires and brakes ready!!!

WE-Todd Octoberfest November 15-16 2008 at CMP

Events will be Free Camping and Free Touring Laps during Lunch both days!

FYI: New CMP track layout and garage/skid pad open during these events!

Location: CMP

http://www.carolinamotorsportspark.com

Link for Registeration and Tech forum!

http://www.turnonetrackevents....s.php

Registration: Open Til 2 weeks before the event date! Novemeber 1st will be cut-off for the Honda Group

http://www.turnonetrackevents.com

Cost: $263.00 for Advanced/Solo Drivers 12 sessions (6 per day) with 10 drivers!

Less then 10 drivers is 300.00. More drivers the cheaper this event will be so register early to save a spot.

$315.00 for Drivers Ed/Instructed Run group

IMPORTANT INFO: To get the discount for the group when registering put on the registration sheet or fax/call whatever.....Make sure they know you are with the HONDA GROUP!!!!!! otherwise you will be charged full amount.

Put this on your registration and tell Tony or Sylivia when registeringHonda Group

After Sat. event we will have a BYOB Cookout and Mini Banquet! The size will be determined based on how many people show up for the event and how many sponsors/people want to participate in a Cookout.

https://honda-tech.com/zero...age=1



Wish I can see a track around Louisiana.

Daily Driven 93 hatch
b20 84mm short block
ctr i/t cam and the rest is a stock b16A2 top half
same b20 header that came with the long block
fidanza flywheel & 6 pucks clutch
2 1/4 pipes with a 2.0" muffler don't like the noise
I rev Pass the 7.5 rpm on ~40% of the time.

Built since '05, but a month ago lend it to a friend since I was fixing his '96 ls hatch that I did the swap back in '06.

My car came back with KNOCKING noises.
I don't want to point finger, but D@mn!!!

Pulled her out of the car a week ago, and finally open her up last night.
ALL 8 VALVES have kissed ALL 4 pistons leaving deep grooves on the ctr i/t side.
...deeper valve travel
Is there a chance that he miss shift and cause the timming to skip a notch???????

Rebuilding this weekend.

12.5 cr pistons
ARP rod and head bolts
FULL gasket/rebuilt kit

Any suggestion while the engine is "open"???
Is there a chance that he miss shift and cause the timming to skip a notch???????

Thanks.


Modified by LilSilver at 12:38 PM 10/3/2008



Sorry to hear about your car, sounds like your friend owes you a rebuild.
How many miles would you say it has on it??

I had a D series that skipped a tooth once but the belt was loose. I would guess that he overreved it, valves floated and you came up short.

I couldn't tell from the info but I wouldn't run the CTR/ITR cams without CTR/ITR valve springs. Also, Your probably loosing a little top end running 2" muffler but I completely understand the noise issue with a DD.

Good luck getting back on the road and keep us posted



Damn I want b20/vtec or h2b setup. nice builds, great thread.



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by Gong Show &raquo;</TD></TR><TR><TD CLASS="quote">Damn I want b20/vtec or h2b setup. nice builds, great thread.</TD></TR></TABLE>
my b20vtec set-up is for sale!! great gas mileage!! good torque power for stock internals.

b20b vtec
untouched block
b16a3 head
GSR cams
JG edlebrock manifold
68mm TB
JDM oem itr header
chipped PO6 ecu
ACT 6 puck clutch
stock flywheel and Pressure plate
98 GSR trans
10 gallon tank on a 94 CX hatch gives me 320 Highway miles

so i guess 32 high way miles per gallons which i think is awesome!!!!



my recent swap. b20bvtec

-b20b stock block
-gsr head with ctr cams
the rest is stock
-skunk2 i/m with stock b16 t/b
-aem intake
-stock b16 headers w/ stock exhaust
-gsr tranny with act heavyduty street clutch/act lightweight flywheel
-mobile 1 synthetic 5w30

Total mileage so far on this motor is about 1800k


this car is dd driven and pushed when needed to. i drive it average 10 miles a week around school (imma college student/some days it looks sad in the parking lot sitting by itself "untouched") and a weekend of driving back home and to school it'll be a 150 miles. So i get about 300 miles to the tank with a little rough driving.

i am very concern about not having this motor tuned. i know theres really no reason to get it professionally tuned but i dont want to take a risk of having the motor blow on me. any suggestions? im only running a stock obd1 p72 ecu.


Modified by GuCBlackEk at 10:13 PM 10/8/2008



<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by GuCBlackEk &raquo;</TD></TR><TR><TD CLASS="quote">my recent swap. b20bvtec

-b20b stock block
-gsr head with ctr cams
the rest is stock
-skunk2 i/m with stock b16 t/b
-aem intake
-stock b16 headers w/ stock exhaust
-gsr tranny with act heavyduty street clutch/act lightweight flywheel
-mobile 1 synthetic 5w30

this car is dd driven and pushed when needed to. i drive it average 10 miles a week around school (imma college student/some days it looks sad in the parking lot sitting by itself "untouched") and a weekend of driving back home and to school it'll be a 150 miles. So i get about 300 miles to the tank with a little rough driving.

i am very concern about not having this motor tuned. i know theres really no reason to get it professionally tuned but i dont want to take a risk of having the motor blow on me. any suggestions? im only running a stock obd1 p72 ecu. </TD></TR></TABLE>

you should get it tuned, at least with an FPR so you aren't driving lean everywhere.
