Honda Civic / Del Sol (1992 - 2000) EG/EH/EJ/EK/EM1 Discussion

Another EK Brake Master Cylinder Upgrade


Old 04-29-2019, 06:58 AM
  #1
Honda-Tech Member
Thread Starter

creizlein's Avatar

Join Date: Nov 2014
Posts: 128
Likes: 0
Received 0 Likes on 0 Posts
Default Another EK Brake Master Cylinder Upgrade

I have a JDM 1998 Civic VTI - (LHD - B16a - ABS - 260mm Font Brakes) which comes stock with a 15/16th MC.
Since I have upgraded my front calipers to Wilwood DPHA 4 piston calipers and braided lines all around my brake pedal travel is way to long, even under hard braking pressure the pedal goes almost to floor and i can barely lock the wheels or actuate the abs.

I am looking to upgrade the Master Cylinder and considering which options do I have in order to keep everything else the same?
Apparently for what I found on the forum if I upgrade to a ITR MC I also have to upgrade the booster, is that really needed or I have any other option to just upgrade the MC?
Should I consider a Nissin/OEM one or does Wilwood makes any decent bolt-on replacement?

Thanks for the feedback as usual
creizlein is offline
Old 04-29-2019, 07:19 AM
  #2
Honda-Tech Member

Freedo_Civegra's Avatar

Join Date: Jan 2018
Location: Mississippi
Posts: 1,116
Likes: 0
Received 0 Likes on 0 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

Ive got an ITR MC on my 2000 EK with OEM booster.
Freedo_Civegra is offline
Old 04-29-2019, 07:26 AM
  #3
Honda-Tech Member

tony_2018's Avatar

Join Date: Nov 2005
Location: Austin, Tx
Posts: 12,887
Received 13 Likes on 10 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

I got a super ITR MC on my LX booster
tony_2018 is offline
Old 04-29-2019, 07:31 AM
  #4
Honda-Tech Member

Freedo_Civegra's Avatar

Join Date: Jan 2018
Location: Mississippi
Posts: 1,116
Likes: 0
Received 0 Likes on 0 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

Originally Posted by tony_2018 View Post
I got a super ITR MC on my LX booster
is it type-r or hype-r?
Freedo_Civegra is offline
Old 04-29-2019, 07:56 AM
  #5
Honda-Tech Member
Thread Starter

creizlein's Avatar

Join Date: Nov 2014
Posts: 128
Likes: 0
Received 0 Likes on 0 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

Originally Posted by Freedo_Civegra View Post
I’ve got an ITR MC on my 2000 EK with OEM booster.
and which size is that one? 1" ? did you had to modify any lines for it to fit?
Does anyone know the P/N of that one? I assume it is an usdm ITR we are talking about
creizlein is offline
Old 04-29-2019, 08:02 AM
  #6
Honda-Tech Member

tony_2018's Avatar

Join Date: Nov 2005
Location: Austin, Tx
Posts: 12,887
Received 13 Likes on 10 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

On the eg civics yes, a line had to be re-bent or a new one had to be made. On the ek it was str8 bolt on.
tony_2018 is offline
Old 04-29-2019, 08:28 AM
  #7
Honda-Tech Member
Thread Starter

creizlein's Avatar

Join Date: Nov 2014
Posts: 128
Likes: 0
Received 0 Likes on 0 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

Originally Posted by tony_2018 View Post
On the eg civics yes, a line had to be re-bent or a new one had to be made. On the ek it was str8 bolt on.
Thanks tony, so I wont have issues I hope, which/where do you recommend to buy? I checked on acura parts and it seems to be discontinued (oem-new one, and i bet its super expensive), rather than a used one any other suggestion/link on which one to get?
creizlein is offline
Old 04-29-2019, 09:33 AM
  #8
Honda-Tech Member

Freedo_Civegra's Avatar

Join Date: Jan 2018
Location: Mississippi
Posts: 1,116
Likes: 0
Received 0 Likes on 0 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

Originally Posted by creizlein View Post
and which size is that one? 1" ? did you had to modify any lines for it to fit?
Does anyone know the P/N of that one? I assume it is an usdm ITR we are talking about
1
no modification
USDM ITR

mine is Centric
Freedo_Civegra is offline
Old 04-29-2019, 09:45 AM
  #9
Honda-Tech Member
Thread Starter

creizlein's Avatar

Join Date: Nov 2014
Posts: 128
Likes: 0
Received 0 Likes on 0 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

Originally Posted by Freedo_Civegra View Post
1
no modification
USDM ITR

mine is Centric
Thanks !!! Centric sounds like a good option, i did a quick search but found both Centric #130-40031 and #130-40033 for ITR, do you happen to know which one ? didnt found any diff honestly.
creizlein is offline
Old 04-29-2019, 11:34 AM
  #10
Honda-Tech Member

Freedo_Civegra's Avatar

Join Date: Jan 2018
Location: Mississippi
Posts: 1,116
Likes: 0
Received 0 Likes on 0 Posts
Default Re: Another EK Brake Master Cylinder Upgrade

Mine is the 13040033.
Freedo_Civegra is offline
